4K-3DCG “MIKOSHI” for HDR

The 4K-3DCG “MIKOSHI” - for HDR - is HDR compatible image material produced by CAD CENTER CORPORATION
with the motif of an imaginary mikoshi. It features 4K full-CG images with HDR color grading.

* It conforms to the "HDR10 Media Profile" included in the HDR compatible display definitions established by the CTA® (Consumer Technology Association).

main

Sample scenes

As sample scenes possible to rent,
we have prepared a 30 sec. version and 73 sec. version.
Standard Dynamic Range (SDR) and
High Dynamic Range (HDR) versions can be selected
for each sample, and you can use
the image quality corresponding to your needs.

Here are the sample videos

* This image is displayed as a low resolution version of the SDR version as it is a sample.

Comparison

The picture shown is a concept.

HDR SDR

HDR(HighDynamicRange)

Since a wide range of brightness levels can be visualized,
it is possible to express images with a high color depth
that cannot be expressed with SDR. In order to play the videos,
a special monitor is needed.

HDR

SDR(StandardDynamicRange)

SDR videos with the standard brightness. Suitable for playing videos on a commonly used monitor and projector.


SDR

Specifications

 HDRSDR
OETFCurve SMPTE ST 2084 Inverse EOTFITU-R BT.709 OETF
VUIcolour_primaries = 9(ITU-R BT.2020)
transfer_characteristics = 16(SMPTE ST 2084)
matrix_coefficients = 9(ITU-R BT.2020 NCL)		colour_primaries = 1(ITU-R BT.709)
transfer_characteristics = 1(ITU-R BT.709)
matrix_coefficients = 1(ITU-R BT.709)
SEIMeta data SMPTE ST 2086: DCI-P3, D65,
Max 1000cd/m2,
min 0.0010cd/m2
MaxCLL: 10000cd/m2
MaxFALL: 133cd/m2(70sec.), 150cd/m2(30sec)		No Meta data
SoundNo sound. Format : 2ch AAC-LC 192 kbpsNo sound. Format : 2ch AAC-LC 192 kbps
File FormatMP4 ContainerMP4 Container
Frame rate29.97fps29.97fps
YUV4:2:0 10bit4:2:0 10bit

Rental Requirements

PeriodOne year from the issuance of the download link.
Payment MethodThe payment method is prepayment by bank transfer.
DeliveryOnly in the form of a download from our data transferring system.
UseLimited to the promotion of display device-related products or internal examination at your company.
CopyMaking copies within your company is permitted, but resale is strictly prohibited.
ModificationAs a general rule, the modification of images (the addition of logos and telops and changing the aspect ratio) is prohibited.
CopyrightCAD CENTER CORPORATION.

* The terms of use are limited to the range of licensing concluded separately.
